10 GB/IE/CY
Note: During use of the blow gun 9 with the
corresponding hose 2 incl. adapter for the
compressor 2 a , there is a small discharge ope-
ning on the adapter 2 a , which releases air. This
serves to create a more uniform airflow for ea-
sier and better handling of the blow gun
9 . This
is not a defect, rather, it serves for better hand-
ling and an improvement of the spray results by
means of a uniform airflow.
Mixing paints for use
The paints included are water-soluble. In order to
properly apply the paints, add water and stir. As
delivered, the paints are too viscous.
First fill the beaker with your selected paint
colour with water.
Now screw the cover back on the beaker and
shake it.
Now use the pipette 11 to remove two drops
of the slightly diluted paint paste and add them
to a paint mixing beaker completely filled with
water (
4 , 5 ).
Shake the beaker. Now your paint has reached
the correct consistency.
Attach the paint mixing glass ( 4 , 5 ) accord-
ing to Ill. B.
Note: If desired, you can adjust the amount of
water added to influence the colour intensity
yourself as with a watercolour box. The more
water you add, the „thinner“ the colour.
You can also mix individualised colour tones
from the available colour pastes. Please take
note, there must be no paint clumps remaining
in the paint containers. The consistency should
correspond to that of water.
Note: If the paint used does not cover well, in-
crease the amount of paint in the mixture ratio.
Turning airbrush compressor
on / off
Turn the airbrush compressor 1 on by setting the
on / off switch 14 to the position “I“ (see Ill. C).
Turn the airbrush compressor 1 off by setting
the on / off switch 14 in the position “0“ (see
Ill. C).
Note: Full pressure is built up after two seconds.
Regulating the air pressure
Regulate the air pressure by actuating the vent
of the air blow gun 9 to more or less of an
extent.
ATTENTION! The device has a pressure switch,
which periodically and automatically turns the de-
vice off if there is excess pressure or if it is not in use.
Shortly before reaching the switch-off point, the
compressor runs more roughly and vibrates. This
may also be the case when re-started under load.
The performance and functionality are not impaired
by this. This is not a defect, rather, serves to protect
the compressor from overloading.
Note: The blow pistol 9 blows air through the
discharge openings even without actuating the trig-
ger. This is
NOT A DEFECT.
Through actuating the trigger, the air discharge is
increased so that more air volume flows.
Note: During use of the blow gun
9 with the cor-
responding hose 2 incl. adapter for the compres-
sor 2 a , there is a small discharge opening on the
adapter 2 a , which releases air. This serves to create
a more uniform airflow for easier and better handling
of the blow gun
9 . This is not a defect, rather, it
serves for better handling and an improvement of
the spray results by means of a uniform airflow.
Regulating the spraying results
Regulate the amount of the paint supplied by
turning the paint nozzle of the spray stylus to
the right or left (see Ill. B).
Preparations for use / Cleaning and care Preparations for use
