Milling Process
Set the milling depth as previously described.
Place the device on the desired work-piece and
switch it on.
Loosen the clamping lever 16 by turning it clock-
wise and pushing the device down until it touches
the surface of the depth stop
12 on the step
stop 9 .
Lock the device into place by turning the clamp
lever
16 anti-clockwise.
Mill with even speed and even pressure (see fig. I).
Set the copy casing
Set the copy casing 26 from below on the slid-
ing bar 8 .
Secure the copy casing 26 with the two screws
22 of the extractor adapter on the base plate 7 .
Ensure that the copy casing 26 is set the right
way round - the thrust ring 25 must be pointing
down (see fig. D).
Milling with the copy casing
Note! The pattern must be at least as high as the
copy casing’s
26 thrust ring 25 .
Note! Chose the router bit as small as the inner
diameter of the copy casing.
When using a copy casing 26 the pattern can be
transferred onto the work piece.
Place the router with the copy casing on the
pattern.
Loosen the clamping lever 16 by turning it
clockwise and lower the device until it reaches
predetermined depth.
Lead the device with the protecting copy cas-
ing along the pattern. Apply pressure lightly.
Milling with a rip fence
Push the rip fence 24 along the guide rail 6 of
the base plate 7 and tighten the screws 5 .
Put the rip fence 24 on the edge of the work
piece (see fig. F, H).
Milling with a circular compass
(see fig. J)
Put the centring pin 30 in the marked mid point
of the circle.
Turn the rip fence 24 over, i.e.the fence side is
facing upwards.
Screw together the centre pin and the rip fence
with a wing bolt. Lock the centre pin to the screws
with the slot of the open-ended spanner
27 .
Maintenance and Cleaning
RISK OF INJURY! Switch the
device off and pull the plug out of the mains socket
before carrying out any work on the device.
Always keep the device clean, dry and free of
oil or grease.
Use a dry cloth to clean the housing.
If the connection cable needs
to be replaced, this repair must be performed
by the manufacturer or a representative to pre-
vent safety hazards.
Warranty
The warranty for this appliance is for 3
years from the date of purchase. The ap-
pliance has been manufactured with care
and meticulously examined before deliv-
ery. Please retain your receipt as proof
of purchase. In the event of a warranty
claim, please make contact by telephone
with our Service Department. Only in this
way can a post-free despatch for your
goods be assured.
The warranty covers only claims for material and
maufacturing defects, but not for transport damage,
for wearing parts or for damage to fragile compo-
