Operation Start-up / Operation
Start-up
Router set / Applications
Original attachment included in delivery:
To profile:
32 Round and profile cutter, 24.7 mm
33 Round and profile cutter, 28.6 mm
34 Round and profile cutter 28.6 mm (R–4)
35 Hollow cutter, 12 mm
36 Hollow cutter, 24.7 mm
37 V-groove cutter, 9.5 mm
38 V-groove cutter, 16 mm
39 Bevel cutter, 32 mm
To connect:
40 Dovetail cutter, 14.3 mm
41 Flush cutter, 12.7 mm
42 Slot cutter, 6 mm
43 Slot cutter, 12 mm
Note: Provided the router’s ball bearing has loos-
ened, tighten it with the Allen key provided in the
router set.
Using the router tool
Press and hold the spindle lock key 10 .
Release the union nut 3 with the open-ended
spanner 27 by turning it anticlockwise.
Release the spindle-lock key 10 .
Then use the router tool. This must be inserted
at least 20 mm (shaft length).
Tighten the union nut 3 firmly with the open-
ended spanner 27 .
Attaching the extractor adapter
Put the extractor adapter 21 on the drilling ex-
tractor 18 provided.
Screw together the extractor’s screws 22 and
the under side of the base plate 7 .
Connect a vacuum device approved for the
extraction of sawdust and splinters to the ex-
tractor
21 (see Fig. G).
Reducer
Connecting:
Slide the reducer 28 in to the suction adapter 21 .
Slide the hose for an approved dust extraction
unit (e.g. a workshop vacuum) onto the reduc-
er
28 .
Removal:
Pull the hose of the vacuum unit off of the re-
ducer
28 .
Pull off the reducer 28 .
Changing the collet
Note: All router bits of the router sets have a 8 mm
shaft.
Start with the already installed collet 8 mm
4 .
Change the collet for a router bit with a 6 mm shaft
as described below.
Release the union nut by turning it anticlock-
wise using the open-ended spanner
27 until
the collet 8 mm 4 is removed.
Insert the collet 6 mm 23 .
ATTENTION! Tighten the union nut 3 firmly
with the open-ended spanner 27 once the rout-
er bit 17 is inserted. Otherwise the collet might
be damaged.
Fitting the guide fence
Unscrew the both of the sliding bar’s 29
screws with a Philips screw driver.
Secure the sliding bar 29 to the rip fence 24
and tighten the screws.
Operation
Switching on and off
Switching on:
Press and hold the start lockout 20 .
Activate the ON / OFF switch 19 . Once the
machine has started, release the start lockout 20 .
