14 GB/IE/CY
Operation / Cleaning / Service / Warranty Operation
Changing the engraving point
RISK OF INJURY! Switch the device off before
performing any tasks on the device and pull the mains plug out of the
mains socket.
Replace the engraving point 5 as soon as it becomes too worn
and no longer provides the desired engraving performance. Turn
the engraving point holder
6 anticlockwise until the engraving
point 5 is released.
Remove the spring and the plain washer.
Push the plain washer and spring on to a new engraving point 5 .
Then insert this and turn the engraving point holder 6 clockwise
to lock the engraving point in position.
Ensure that the engraving point 5 is properly fixed in position.
Advice on use
You can use the mini-engraver to produce creative, individual engravings.
For example, you can use it to place identifying marks on your valuables.
You can engrave numbers and letters into metal, glass, wood, plastic,
ceramic, stone and leather. This is done with the help of the supplied
engraving stencils
7 , see Figs. A and B.
Hold the device at an angle, as you would a pencil.
Your arm should rest on the table.
Using very light pressure, guide the engraving point 5 over the
workpiece. Find the ideal speed of movement by trial and error on
a piece of waste material.
