Fixing the Wheels

The back wheels on the chassis (9) can be

ixed in order to secure the pressure wash-
er against undesired rolling away.

• To do this push the two bolts (16) out-

wards and downwards.

The wheels are now no longer able to
turn.

• To cancel the wheel ixing, push the

two bolts (16) upwards.

F

Removing the Chassis

The pressure washer can also be used
without the chassis (9).

• Press the release button (18) on the

front locking point. Hold the chassis (9)
securely in the front area and pull the
pressure washer upwards.

At the same time, tilt the pressure
washer slightly to the rear.

• To reinstate, insert the device into the

rear area of the chassis (9). Push down
on the device down and press the re-
lease button (18) at the same time. The
device clicks into the chassis.

Cleaning and Mainte-
nance

Pull out the power plug before

every maintenance operation. There
is a risk of electrocution or of injury
from moving parts.

Cleaning

Never direct the water jet

against the washer, nor clean

the washer under lowing
water. This could give rise to
the danger of electric shock
and damage the washer! .

Always keep the washer clean. Do
not use any detergents or solvents.

• Always keep the ventilation slots clean

and free.

• Only clean the pressure washer with a

soft brush or a slightly moist cloth.

• In case a nozzle of the jet tube

(12/13) is clogged up, use the nozzle
cleaning pin (15) to remove the object
from the nozzle.

G

If necessary, take off the water con-

nection with the ilter insert (8) and

clean the ilter insert.

Maintenance

The pressure washer is maintenance free.

Ask our service centre to carry out

any work that is not described in
these instructions. Use only original
parts.

Storage

• Drain all the water from the pressure

washer. Disconnect the unit from the
water supply. Press the On/Off switch
(

A

5) to turn on the pressure washer

for no longer than 1 minute until no
more water escapes from the high-
pressure connection (

A

5). Turn off the

unit.
