General description
The illustration of the principal
functioning parts can be found
on the front and back foldout
pages.
Extent of the delivery
Carefully unpack the appliance and check
that it is complete.
The appliance is supplied with the motor
head fitted ( 3). To remove the motor
head, open the sealing clips ( 4).
3 Motor housing
5 Collector
6a 2 feet with wheels and acces-
sory fittings
6b 2 feet with castors and acces-
sory fittings
11 Fluted filter (11a) and filter
cover (11b) (already installed)
12 Paper filter bag
13 Foam filter
14 Accessory bag
15 Handle with air regulation
16 Telescopic suction tube
18 Vacuum hose
19 Powertool hose
20 Powertool reduction adaptor
piece
21 Switchable household nozzle
22 Crevice nozzle
23 Cushion nozzle
24 Car nozzle
25 2 retaining brackets
4 cross recessed screws
Instruction Manual
Dispose of the packaging material cor-
rectly.
Overview
Housing
1 Carrying handle
2 Mains power cable
3 Motor housing
4 Sealing clip
5 Collector
6a 2 feet with wheels and acces-
sory fittings
6b 2 feet with castors and acces-
sory fittings
7 Drainage outlet
8 Suction connection
9 Appliance socket
10 On/off switch
Filter
11 Fluted filter (11a) and filter
cover (11b) for dry vacuuming
(already installed)
12 Paper filter bag for fine dust
13 Foam filter for wet vacuuming
Accessories
14 Accessory bag
15 Handle with air regulation
16 Telescopic suction tube
17 Vacuum tube holder
18 Vacuum hose
19 Powertool hose
20 Powertool reduction adaptor
piece
for connecting electrical equip-
ment for dust extraction.
Nozzles
21 Switchable household nozzle
for vacuuming carpets
for vacuuming smooth surfaces
22 Crevice nozzle
23 Cushion nozzle
24 Car nozzle
