42 GB
If a dangerous situation arises, pull
the mains plug immediately out of the
mains socket. Ensure that the device and
the mains plug are easily accessible and can
be reached quickly in an emergency.
When taking a break from your
work, before carrying out any tasks
on the device itself and when you are
not using the device, always pull the
mains plug out of the mains socket.
Always keep the device clean, dry and free of
oil or grease.
Remain alert at all times! Always watch
what you are doing and proceed with
caution. Do not use the device if you cannot
concentrate or you are feeling unwell.
Q Preparing for use
Q Attaching the disc guard cover
using the quick-release fastener
DANGER OF INJURY!
Pull the mains plug out of the mains
socket before you carry out any task
on the device.
DANGER OF INJURY! Always use the
angle grinder with the disc guard
cover in place. The disc guard cover must
be securely attached to the angle grinder. To
ensure the highest level of safety while using
the device, ensure that the smallest possible
area of the grinding or cutting tool is exposed
to the operator at all times. The disc guard cov-
er is there to protect the operator from pieces
breaking off and accidental contact with the
grinding or cutting tool.
DANGER OF INJURY! Ensure that the
guard 7 is attached so that its edge
is beyond the angle of the auxiliary
handle
6 (see Fig. B). Otherwise you
could injure yourself against the grinding or
cutting disc.
Open the clamping lever 8 .
Insert the disc cover guide 7 with the coded
projection 9 in the coded groove 16 .
Turn the disc guard cover 7 into the desired
position (working position). The closed side of
the disc guard cover
7 must always be facing
the operator.
Close the clamping lever 8 to firmly clamp
the disc guard cover 7 in place.
If necessary the clamping force of the connection
can be adjusted by tightening or loosening the
adjuster screw
10 .
Ensure that the disc guard cover 7 sits firmly
on the spindle collar.
Q Attaching the auxiliary handle
CAUTION! For safety reasons this
device must always be used with the
auxiliary handle
6 in place. Otherwise
you could become injured.
DANGER OF INJURY!
Pull the mains plug out of the mains
socket before you carry out any task
on the device.
Screw the auxiliary handle 6 on the left, right
or on the top of the head of the device.
Q Attaching and replacing
roughing / grinding / cutting discs
Take note of the dimensions of the roughing /
grinding or cutting discs. The circular hole must fit
on to the mounting flange without play. Do not use
a reducer piece or adapter.
DANGER OF INJURY!
Pull the mains plug out of the mains
socket before you carry out any task
on the device.
Check the condition of the roughing /
grinding or cutting discs. They must be
free of damage, moisture or cracks.
Otherwise they could break up during use and
cause injury.
DANGER OF BURNS! Always wear
protective gloves when changing a
roughing / grinding or cutting disc.
Roughing / grinding and cutting discs become
Preparing for use / Operation / Maintenance and cleaning General power tool safety warnings / Preparing for use
