hot during use. Do not touch them until after
they have cooled down.
NOTE: Always ensure the discs are free of dirt
before use.
Use only abrasive consumables or tools with
an allowable speed at least as high as the
no-load speed of the device.
DANGER OF INJURY! Press the spindle lock
button
11
only after the mounting spindle
14
has reached a standstill.
Press the spindle lock button
11
to block the drive.
Release the clamping nut
13
using the spanner
17
(see Fig. C).
Place the roughing / grinding or cutting disc on
to the mounting flange
15
with its labelled side
facing towards the device.
Then replace the clamping nut
13
, with its
raised side facing upwards, on to the mounting
spindle
14
.
Press the spindle lock button
11
to block the drive.
Tighten the clamping nut
13
again with the
spanner
17
.
NOTE: Replace a new disc immediately if it
runs unevenly or vibrates after being exchanged.
After replacing a disc let the device run under
no-load conditions for 30 seconds as a safety
check. Look out for unusual noises or generation
of sparks. Check that all the fastened-on parts
are correctly attached.
Pay attention to see that the arrow showing the
direction of rotation on the roughing / grinding
or cutting discs (including diamond cutting discs)
corresponds with the direction of rotation of the
device (see arrow on the head of the device).
Q
Operation
Q
Switching on and off
Note: Always switch on the angle grinder before
bringing it into contact with the workpiece material.
Switching on the device:
Press the safety lock-out
3
(see Fig. G).
Then press the ON / OFF switch
2
.
Switching off the device:
Release the ON / OFF switch
2
.
Rotating the hand grip:
DANGER OF INJURY!
Pull the mains plug out of the mains
socket before you carry out any task
on the device.
The hand grip
1
can be rotated by 90° to
the right or left (see Fig. A).
This allows the ON / OFF switch
2
to be
brought into the most comfortable position for
any working conditions.
Press the unlocking button
4
and rotate the
hand grip
1
to the right or left.
Make sure the hand grip
1
engages.
Q
Maintenance and cleaning
DANGER OF INJURY!
Pull the mains plug out of the mains
socket before you carry out any task
on the device.
Do not use sharp objects for cleaning
the device. Do not allow any liquids
to enter the device. Otherwise the device
could be damaged.
Have the carbon brushes replaced only at the
service centre or an accredited electrical
equipment repair centre. The device requires
no other maintenance.
Clean the device frequently; for best results do
this immediately after you have finished using it.
Use a dry cloth to clean the housing – under
no circumstances use petrol, solvents or cleaning
agents that attack plastic.
A vacuum cleaner is required to thoroughly
clean the device.
Ventilation openings must always be kept free.
Remove any adhering dust with a narrow paint
brush.
