12 GB
extraction. To do so, open the hook-and-loop
fastener at the side of the dust bag
10 .
Adding oil
To ensure a long service life for the compressed air
orbital sander the unit must always be adequately
filled with pneumatic oil.
You may ensure this in any of the follow-
ing ways:
Connect a service unit with an oiler to the
compressor.
Install a compressed air oiler in the air line or
to the compressor.
Manually add approx. 3-5 drops of pneumatic
oil to the plug nipple 3 every 15 operating
minutes.
Initial use
Connecting the compressed
air source
Note: Only operate the compressed air orbital
sander with cleaned, condensate-free compressed
air. Never exceed the unit‘s maximum operating
pressure of 7.5 bar.
Note: The compressed air source must be fitted
with a (filter) / pressure reducer to allow the air
pressure to be regulated.
Switching on and off
Note: Always switch on the compressed air orbit-
al sander before bringing it into contact with the
work piece.
Switching on the compressed air orbital
sander:
Press the operating lever 1 all the way down
(see Fig. C).
Adjust the speed with the speed control 5 .
Switching off the compressed air orbital
sander:
Release the control lever 1 .
Disconnect the unit from the compressed air
source after finishing the work.
Note: First disconnect the hose from the
compressed air source (compressor), only then
disconnect the supply hose from the unit. This
will ensure that the compressed air supply hose
does not wave around or recoil in an uncon-
trolled manner.
Working instructions
Wait until the device has come to a standstill
before you put it down.
Sanding surfaces
Switch on the compressed air orbital sander,
place the entire sanding surface on the surface
to be worked and move it across the work
piece with moderate pressure (see Fig. D).
Note: The sanding output and pattern greatly
dependent on the sanding disc selected and
the pressure applied. Only grinding discs that
are in perfect condition will provide good
grinding performance.
Be sure to apply pressure evenly to increase
the life of the sanding discs.
A sanding sheet previously used on metal must
not be used on other materials.
Replacing the backing plate
RISK OF INJURY! Always
disconnect the device from the compressed air
source before you replace the backing plate
6 .
Push the open-ended spanner 11 between the
backing plate 6 and collar 7 .
Release the backing plate 6 by turning the
plate anticlockwise and holding the open-ended
spanner
11 still against this movement.
