Introduction
Introduction / Safety instructions
Air Sander PDEXS 150 A1
Introduction
Congratulations! You have chosen a
high-quality device from our company.
Familiarise yourself with the product
before using it for the first time. In addition, please
carefully refer to the operating instructions and the
safety advice below. Initial operation of this tool
must be performed by trained personnel.
KEEP OUT OF THE REACH OF CHILDREN!
Intended use
The compressed air orbital sander is suitable for
sanding, polishing and preparing various surfaces.
Keep these instructions in a safe place. When pass-
ing this product on to others please also include all
documents. Any use not specified is prohibited and
potentially dangerous. Damages resulting from
noncompliance or misuse are not covered by the
warranty and are not included in the manufactur-
er‘s liability. This device has been designed for
household use and may not be used for commercial
or industrial purposes.
Features
Check that all the items are present and
that the product is in perfect condition
immediately after unpacking. Never use
the product if it is defective.
1
Trigger / control lever
2
Connection for dust extraction
3
Male coupling ¼"
4
Compressed air connection (for male
coupling ¼")
5
Speed control
6
Sanding plate with hook and loop fastener
7
Collar
8
Housing
9
Exhaust air hose
10
Dust bag
11
Open-ended spanner (22 mm) for replacing
the sanding plate
Technical Data
Max. working pressure: 7.5 bar
Working pressure:
5.8–6.8 bar
Sanding plate:
ø 150 mm
Speed:
10500 min
-1
Operating stroke:
4.8 mm
Sound power level:
84 dB(A)
The following pictograms are used in these operating instructions / on the device:
Read instruction manual!
Observe caution and safety notes!
Note
Keep children away from the device!
For your own safety, wear suitable
personal protective equipment.
Dispose packaging and appliance in
an environmentally-friendly way!
Remove abrasive dust with a brush.
