11 GB/CY
Operation Operation / Maintenance and Cleaning / Service / Warranty
Make a circle on the work piece.
Mark the centre and drill a hole into the hole
(plunge cut).
Drill a guide hole on the edge of the circle
(plunge cut) (guide hole diameter 3 mm).
Loosen the wing bolts 9 in the foot plate 7
and slide the guide rod for the circle- / rip
fence set
15 through the two holes in the bot-
tom of the base plate 7 , with the centring tip
facing down.
Insert the centring tip in the middle of the circle.
Adjust the distance of the circle- / rip fence set 15
so as to plunge the bit into the guide hole at
the edge of the circle.
Lock the base plate 7 by tightening the wing
bolts 9 .
Press and hold the ON / OFF switch 4 to
power on the unit.
Slowly push the unit forward.
Dust extraction (see Fig. I)
The tool features a dust extraction nozzle 6
to vacuum off dust.
Insert the adapter 19 in the extraction nozzle 6 .
Connect a vacuum cleaner to the adapter 19 .
Continuous tool operation
Locking the ON / OFF switch 4 :
Activate the ON / OFF switch 4 .
Press the locking switch 1 and release the
ON / OFF switch 4 .
Unlocking the ON / OFF switch 4 :
Activate the ON / OFF switch 4 and release.
Maintenance and Cleaning
The device requires no maintenance.
Clean the unit promptly after use.
Clean the device with a dry cloth, never use
petrol, solvents or cleaning agents harmful to
plastic.
Always keep the vents clear.
Remove dust clinging to the sander with a brush.
Service
Always have your
device repaired by qualified specialist
personnel using only original manu-
facturer parts. This will maintain the safety
of the device.
If the plug or mains
lead needs to be replaced, always have
the work performed by the manufac-
turer or its service centre. This will maintain
the safety of the device.
Warranty
The warranty for this appliance is for 3
years from the date of purchase. The ap-
pliance has been manufactured with care
and meticulously examined before deliv-
ery. Please retain your receipt as proof
of purchase. In the event of a warranty
claim, please make contact by telephone
with our Service Department. Only in this
way can a post-free despatch for your
goods be assured.
The warranty covers only claims for material and
maufacturing defects, but not for transport damage,
for wearing parts or for damage to fragile compo-
nents, e.g. buttons or batteries. This product is for pri-
vate use only and is not intended for commercial use.
The warranty is void in the case of abusive and im-
proper handling, use of force and internal tampering
not carried out by our authorized service branch. Your
statutory rights are not restricted in any way by this
warranty.
The warranty period will not be extended by repairs
made unter warranty. This applies also to replaced
