27 GB
Introduction / General safety instructions for air tools Introduction
Features
Check that all the items are present and that the
product is in perfect condition immediately after
unpacking. Never use the product if it is defective.
1 Housing
2 Transport handle
3 Air hose with quick-disconnect coupler
4 On / Off Switch
5 Hose with valve adapter
6 Pressure gauge
7 Blow-out adapter
8 Tapered universal adapter A
9 Tyre filling device
10 Ball needle
11 Valve adapter
12 Deflating valve adapter
13 Screw-on valve adapter
14 Deflating adapter
15 Additional adapter
16 Tapered universal adapter B
Technical Data
Rated voltage: 220 - 240 V ~ 50 Hz
Power rating: 1.1 kW
Duty type: S3 15 % 10 min
Compressor speed: 3550 rpm
Operating pressure: max. 8 bar
Theo. Suction capacity: 180 l / min
Noise level L
pa
: 74.9 dB (A)
Uncertainty K
pa
: 1.93 dB (A)
Sound power level L
wa
: 94.9 dB (A)
Uncertainty K
wa
: 1.93 dB (A)
Guaranteed
Sound power level:
97 dB (A)
Protection type: IP20
Device weight: approx. 6.0 kg
Measured value
corresponds to:
ISO 2151
Noise emission measured according to ISO 2151
Duty type S3-15 %-10 min: S3 = Intermittent duty
without the effect of starting. During a 10 min pe-
riod the max. operating time is 15 % (1.5 min).
General safety
instructions for air tools
Note: When used in the following text, the terms
„compressed air unit“ or „device“ refer to the com-
pressed air unit specified in these instructions for
use. Basic safety measures must be followed when
using compressed air units to eliminate the risk of
fire, electric shock and personal injury. Be sure to
read and follow the notices within these operating
instructions prior to using the device and store them
in a safe location. The manufacturer assumes no
liability for damages or personal injury resulting
from failure to follow these operating instructions.
This appliance may be used by children age
8 years and up, as well as by persons with re-
duced physical, sensory or mental capacities,
or lacking experience and / or knowledge, so
long as they are supervised or instructed in the
safe use of the appliance and understand the
associated risks. Children should not be allowed
to play with the device. Cleaning and user
maintenance should not be performed by
children without supervision.
RISK OF INJURY!
During maintenance, switch off the compressed
air supply.
Only use the device in areas of application for
which it was designed!
Do not overburden the device. Never use
hydrogen, oxygen, carbon dioxide or other
bottled gasses to power this tool as doing so
may result in an explosion and thus may cause
severe injuries.
Maintain and clean the device regularly as
instructed (see Chapter „Cleaning / care“).
EXPLOSION HAZARD!
Never use petrol or other flammable liquids to
clean the air tool! Sparks could ignite residual
vapours inside the compressed air unit resulting
in the compressed air unit exploding.
