30 GB
... / Cleaning / Care / Spare ... / Maintenance and ... /Information about ... General safety information for electrical devices / Before use / Start-up
always use the handle on the device to move
it. Never touch the device itself!
ATTENTION! The compressor housing may
become hot during use. Do not touch hot sur-
faces in order to prevent burns.
Never leave the device in operation unattended.
Built-up heat generated by the device can be a
source of danger. This compressor is equipped
with overheat protection. Of the motor reaches
a temperature of 130 °C, the overheat protec-
tion will automatically shut it off. This allows the
motor to cool off, thus preventing damage. Once
the motor has cooled down, it will automatically
restart. This pause is normal and is intended to
protect the motor. This process will repeat if the
motor again reaches a temperature of 130 °C.
Only use indoors.
WARNING! The compressor can start up
without warning!
Before use
Only use the compressor in dry, well ventilated
rooms. The room must be free from dust, acids,
fumes, explosive or flammable gasses.
Check that all of the device‘s parts are in per-
fect condition.
Make sure that the available mains voltage is
compatible with the voltage intended for oper-
ating the compressor.
Avoid long supply lines.
Place the compressor on its rubber feet before
use.
Note: The switch light indicates the mains connec-
tion and does not indicate pump operation.
Start-up
Switching the compress
on / off (cf. Fig. A)
Please set the on / off switch 4 to position I to
switch on.
Please set the on / off switch 4 to position 0
to switch on.
Establishing connections
(cf. Fig. B)
ATTENTION! Switch off the device for this
purpose. Please hold on to the coupling to
prevent injuries due to the hose rebounding.
Connect the nipple of your air tool to the com-
pressor‘s air hose
3 .
To disconnect this connection, pull back on the
quick-disconnect coupling of the air hose
3 .
Using the tyre filling
device (cf. Fig. C)
The compressed air tyre filling device 9 is used to
inflate car tyres and, used with the appropriate ac-
cessories, also to inflate and control bicycle tyres,
rubber dinghies, air mattresses, balls, etc.
ATTENTION! The pressure gauge
6 is not cali-
brated! Please check the air pressure with a cali-
brated device after filling.
Using the blow-out gun
(cf. Fig. D)
The tyre filling device 9 can also be used to clean
hollow spaces and dirty surfaces and tools when
used as a blow-out gun.
To do so, please first remove the hose with
valve adapter
5 .
Now attach the blow-out adapter 7 with the
tyre filling device 9 .
