28 GB
Safety instructions / Before use
Please ensure that this device was not intended for
commercial use. We do not accept any warranty li-
ability if the device is used for commercial, manual,
or industrial operations, or activities similar to these.
Technical Data
Generator: Synchronic
Protection type: IP23M
Continuous output P
rated
(S1):
2600 W
Maximal output P
max
(S2 2 min):
2800 W
Nominal voltage U
rated
: 2 x 230 V∼
Rated current I
rated
: 11.3 A
Frequency F
rated
: 50 Hz
Type drive motor: 4 stroke air-cooled
Engine displacement: 207.7 cm³
Fuel: Petrol
Tank capacity: 15 l
Engine oil: approx. 0.6 l
(15 W-40)
Use at ⅔ engine load: approx. 1.36 l/h
Weight: 42.5 kg
Sound pressure level L
pA
: 76 dB(A)
Sound power level L
WA
: 96 dB(A)
Uncertainty K: 2.07 dB(A)
Power factor cos ϕ: 1
Performance class: G1
Max temperature: 40 °C
Max. installation altitude
(üNN):
1000 m
Spark plug: F7 RTC
Quality class: A
Operating mode S1 (long use)
The machine can be used continuously with the
indicated power.
Operating mode S2 (Short term use)
The machine can be used in the short term with the
indicated power 2 min.
Acceptable ambient temperature:
-10 to +40 °C
Height: 1000 m above NN
rel. air humidity: 90 % (not condensed)
Before use
Installation
You will need two open ended spanners
for install this device (spanner size 12).
Install the stand 17 , wheels 15 and the push
bar 19 as shown in figures F–I.
Install all parts before pouring in the fuel and
oil to avoid the fluids leaking.
To install the wheels first push the wheel axle 16
through the brackets on the underside of the
generator and install the wheels
15 as shown
in figure G.
Ensure that when installing the push bar 19 the
slanting side (fig. I / Pos. I1) is slanting outwards.
Electrical safety
Electrical cables and attached devices must be
defect free.
Never connect the generator to the mains
(power point).
Keep the cables as short as possible.
Environmental protection
Dispense of polluted maintenance and operating
materials in a suitable collection point.
Earthing
Earthing is needed to disperse static discharge.
Connect a cable from one side of the earthing
