6 GB/IE/CY
Introduction
Hammer drill PBH 1050 A1
Introduction
Congratulations on your new product. You have se-
lected a high quality product. The instructions for use
are a part of this product. They contain important
information about safety, use and disposal. Before
using the product, please familiarise yourself with
all the operating and safety instructions. Only use
the product as described and for the indicated pur-
pose. When passing this product on to others please
be sure to also include all of its documentation.
Intended use
The hammer drill and chisel hammer PBH 1050 A1
is suitable for:
- Hammer drilling bricks, concrete and stone
- Chiseling concrete, stone and plaster
- Drilling stone, wood and metal
Any other use or modifying the device is considered
improper use and involves considerable accident risks.
The manufacturer is not liable for damage caused
by improper use.
The device is not intended for commercial use.
Pictured components
1
Wing screw
2
Clockwise / counter-clockwise switch
3
ON / OFF switch
3 a
Speed setting
4
ON / OFF switch locking button
5
Light emitting diode
6
Function selector switch
6 a
Release button for function selector switch
7
Additional handgrip
8
Tool holder
9
Dust cover
10
Locking sleeve
11
Depth stop
Scope of delivery
1 Hammer drill PBH 1050 A1
1 Additional handgrip
1 Quick-release chuck with adapter (see Fig. A)
3 Drills (see Fig. B)
1 Flat chisel (see Fig. B)
1 Pointed chisel (see Fig. B)
1 Depth stop
1 Tin of lubricating grease
1 Carrying case
1 Set of operating instructions
Technical Data
Rated input power:
1050 W
Rated voltage:
230 V∼, 50 Hz
Idle speed:
n
0
0–980 / min
Impact frequency:
0–5300 / min
Impact energy:
3 joules
Drilling capacity:
max. 13 mm in steel
max. 32 mm in wood
max. 26 mm in concrete
Protection class:
II /
Noise and vibration data:
Measured sound value determined according to
EN 60745. The A-rated noise levels of the electrical
power tool are typically at:
Hammer drilling:
Sound pressure level: 91.26 dB(A)
Sound power level:
102.26 dB(A)
Uncertainty K:
3 dB
Chiselling:
Sound pressure level: 93.44 dB(A)
Sound power level:
104.44 dB(A)
Uncertainty K:
3 dB
Wear hearing protection!
The total vibration (vector sum of three directions) is
calculated in accordance with EN 60745:
