Assembly
(Images are examples for all
product variations)
The product is delivered folded up in its
transport condition. To make it ready to ride,
proceed as follows:
Unfold (Fig. A)
1. Loosen the lower quick-release fastener (1).
2. Pull the lever (2) upward and fold the stee-
ring post (3) forward until it locks in.
3. Secure the folding mechanism by fastening
the lower quick-release fastener.
Attach handlebars (Fig. B)
1. Release the handlebars (4) from the
holders (5).
2. Press down on the locking buttons (6) on the
handlebars and push the handlebars into the
T-pipe (7) on both sides of the steering
column. The locking buttons must audibly
click into the designated holes (8).
Adjusting the steering post
height (Fig. C)
The steering post can be adjusted to
four different heights. Only use the pro-
duct after clicking the locking button
into one of the four holes and securing
the steering post with the quick-release
fastener!
1. Loosen the quick-release fastener (9) on the
steering post.
2. Pull the steering post (10) upward until the
locking button (11) locks into one of the four
holes (12).
3. Secure the steering post by tightening the
quick-release fastener.
Steering head bearing (Fig. D)
The steering head bearing is preset at the time
of delivery. In the event the handlebar has too
much play after some time or become too stiff,
have the steering head bearing adjusted by a
speciality retailer or a bicycle shop.
To put the product back into
its transport condition
1. Loosen the quick-release fastener on the
steering post, press the locking button, push
the steering post all the way in, then tighten
the quick-release fastener.
2. Press the locking buttons on the handles, pull
the handles out of the T-bar and secure to the
holders.
3. Loosen the lower quick-release fastener
(Fig. E) and pull the lever (2) upward, push
the steering post toward the deck until it locks
in (Fig. F). Tighten the lower quick-release
fastener (Fig. G).
Use
Riding, braking, parking
(Fig. H)
• Place one leg on the deck (13) and regularly
push off with the other leg for momentum.
• Step on the brake plate to brake (14).
• Unfold the kickstand (15) to park.
The product may only be parked on a
smooth surface.
Maintenance
Replacing the wheels (Fig. I)
Important!
Please observe the technical data.
Wheels that have a different diameter
can change the riding properties and, in
some cases, possibly endanger the user.
Do not use wheels that cannot be per-
fectly mounted. Never mount wheels
that are larger than the product’s origi-
nal wheels.
Wheels wear out. This wear and tear results from
many factors, for example the ground, the user’s
size and weight, the weather conditions, the ma-
terial of the wheels and their durability. It is thus
necessary to replace them from time to time.
• Remove the axle bolts (16) using two setscrew
wrenches size 5.
• Remove the axle bolts and remove the wheel.
• Attach the new wheel (17) and secure with
the axle bolts.
