Introduction
LED rope light
Introduction
Before assembling and using the device
for the first time, take time to familiarise
yourself with the product first. In addition
please refer carefully to the installation and operating
instructions below and to the safety advice. Only
use the product as described and for the designated
areas of application. Please keep these instructions
in a safe place. If you hand this product on to a
third party, you must also pass on all documents
relating to the product.
Intended Use
This product is suitable for indoors and outdoor
use as decorative lighting. The appliance is only
intended for use in private households, and not
intended for commercial use.
Delivery scope
1 x LED rope light 10 m
20 x Attachment clips
20 x Cable tie
20 x Screw
1 x Operating instructions
Description of parts
1 LED rope light
2 Attachment clips
3 Cable tie
4 Screw
Technical data
Rope light
Operating voltage:
230–240 V ∼ 50 Hz,
(22.5 W)
Bulbs: 240 x 3 V , 0.06 W
Note: bulbs are non-
replaceable.
Ambient temperature: from –15 °C to +30 °C
Protection class:
IP class:
IP44 (splash-proof)
Length: 10 m
LED rope light (Model No. Z30252A / B / D / E)
TÜV / GS tested
Z30252A – transparent
Z30252B – green
Z30252D – yellow
Z30252E – blue
4 20 x
3 1 1 x 2 20 x 3 20 x
