5 GB/IE
Installation safety instructions
Make sure that the product is only installed by
competent persons.
The LED rope light 1 can be installed on all
normally inflammable surfaces with the enclosed
mounting parts.
CAUTION! RISK OF ELECTRIC SHOCK!
Make sure that there are no power, gas or water
lines located where you wish to drill. Check with
a cable and pipe locator if necessary before
you begin drilling.
Before installation, check whether the surface is
suitable for the mounting parts and the weight
of the LED rope light
1 . If you are in any doubt,
consult an electrical specialist for advice.
Do not use sharp and / or pointed objects such
as wire, nails or fasteners for mounting.
Do not attach any additional objects to the
LED rope light 1 .
Avoid excessive bending of the LED rope
light 1 . This can damage the insulation.
The bending radius of the rope must not fall
below the following value: rope diameter
between 10–14 mm: 2 cm.
Avoid excessive heating of the LED rope light 1 .
A maximum of two sections of rope may cross
or run parallel to each other.
Installation
Note: The LED rope light 1 can be mounted on
all surfaces officially classified as being of “normal
flammability” by means of the supplied attachments.
Note: You will need a crosshead screwdriver in
order to mount the attachment clips
2 and
screws 4 .
Use the supplied attachment clips 2 and / or
the cable ties 3 to install the product.
Use
Plug the mains plug into the socket.
The lighting is switched on.
To turn the lighting off, remove the mains plug
from the socket.
Cleaning and care
CAUTION! RISK OF ELECTRIC
SHOCK! First remove the mains plug
from the socket.
Do not use any solvents, petrol or similar items.
This would damage the device.
Only a dry, lint-free cloth should be used for
cleaning.
Service
GB
Service Great Britain
Tel.:
0871 5000 720
(0,10 GBP/Min.)
e-mail: [email protected]
IAN 66409
IE
Service Ireland
Tel:
1890 930 034
(0,08 EUR/Min. (peak)
0,06 EUR/Min. (off peak))
e-mail: [email protected]
IAN 66409
Safety information / Installation / Use / Cleaning and care / Service
