27 GB
Tighten the lower eccentric section 21 a with the lower seal 22
hand tight below the washbasin and verify the eccentric rod 19 is
facing to the back.
Attach the clamping plate and the eccentric joint 20 to the eccen-
tric rod 19 .
Attach the pull rod 18 and the eccentric rod 19 to the eccentric
joint 20 .
Verify the eccentric 21 is functioning properly. The screw below
the drain plug may possibly need to be adjusted. Then secure with
the counter nut again.
Verify the seals 16 are inserted in the swivel nuts on the connect-
ing hoses 15 .
Screw the connecting hoses 15 onto your angle valves. Be sure to
correctly attach the two connecting hoses 15 to the cold and hot
water connections.
Start-up
After the initial commissioning, carefully check all connections for leaks.
To remove any possible impurities the tap must be flushed before being
used for the first time. To do this, proceed as follows:
Unscrew the aerator 9 from the fitting body 8 .
Open the main water supply and allow the water to flow for two
minutes to flush out any residues.
Then reattach the aerator 9 to the fitting body 8 .
