26 GB
Insert the fitting base seal 11 into the groove at the underside of
the fitting body 8 and place it over the opening on your sink unit.
Under the sink unit first place the C-sealing washer 12 , then the
C-metal washer 13 onto the threaded bolt 14 .
Now attach the fastening nut 15 to the threaded bolt 14 and
tighten with an open-end spanner SW 12 mm until the fitting is
seated firmly on the sink unit.
Verify the swivel nuts for the connecting hoses 16 have seals 17 .
Screw the connecting hoses 16 onto your angle valves. Be sure to
correctly attach the two connecting hoses 16 to the cold and hot
water connections.
Start-up
After the initial commissioning, carefully check all connections for leaks.
To remove any possible impurities the tap must be flushed before being
used for the first time. To do this, proceed as follows:
Unscrew the aerator 10 from the sprayer 9 .
Open the main water supply and allow the water to flow for two
minutes to flush out any residues.
Then reattach the aerator 10 to the fitting spout 9 .
Operation
Note: If the tap has not been used for a long period, flush the pipes
thoroughly to avoid stagnation and build-up of residue.
