29 GB
Deactivating the hot water flow limitation:
Attach the hot water limiting ring 6 as shown in Fig. C / I (neutral
setting).
After adjusting the scald protection, attach the cartridge locknut
5 , the cartridge covering ring 4 and the lever 1 analogue to
the disassembly.
Maintenance and Cleaning
Maintaining and cleaning the tap
Please note that sanitary taps require special care and attention.
Therefore, please follow the instructions:
When cleaning, never use petrol, solvents, aggressive cleansers or
hard cleaning brushes etc. These could damage the surface of the
product.
Dry your taps with a cloth after every use in order to avoid the
build-up of any limescale.
Clean the product with a damp, soft cloth and a mild cleaning
agent if required.
Unscrew and remove the aerator 10 at regular interval and remove
any residues of scale or foreign bodies. If heavily contaminated or
damaged, replace the aerator
10 .
Note: The aerator 10 can normally be unscrewed by hand. Oth-
erwise use an open-end spanner SW 22 mm and be sure to place
a thin, damp cloth around the aerator
10 to prevent damaging it.
A pipe wrench with plastic jaws is also suitable.
Non-observance of the above care advice can be expected to result in
damage to the surfaces of the product. This will void the warranty.
