4 GB/IE
Children or other individuals who do not know
or have no experience of handling this device,
or whose physical, sensory or mental abilities
are restricted, must not use the device without
supervision or instruction by an individual
responsible for their safety. Children must be
supervised in order to ensure that they do not
play with the device.
The supply cord cannot be replaced. If the
cord is damaged the appliance should be
scrapped.
Attention! The toilet seat should not be
installed on zone 1 of the shower area.
Zone 1 Zone 2 Zone 3
Shower
area
0,60 m
The silicon cap 9 should be inserted into the
toilet seat when the DC jack 12 of the battery
box 10 is removed. Otherwise, the toilet seat 8
is not spraywater protected.
Battery Safety Instructions
DANGER TO LIFE! Keep
batteries out of the reach of children. Do not
leave batteries lying around. There is a risk of
children or animals swallowing them. Consult a
doctor immediately if a battery is swallowed.
EXPLOSION HAZARD! Never
recharge, short-circuit and / or open
batteries. This can cause them to
overheat, burn or burst. Never throw batteries
into fire or water. The batteries may explode.
Remove exhausted or old batteries from the
product immediately. Otherwise there is an
increased risk of leakage. Battery fluids can
damage the product.
Always replace all the batteries at once with
batteries of the same type.
Check the batteries at regular intervals for leaks.
Leaked or damaged batteries can
cause chemical burns if they come
into contact with the skin; in such
cases you must wear suitable protective gloves.
Avoid contact with the skin, eyes and mucous
membranes if fluid has leaked from the battery.
In the event of contact with battery acid, rinse
the affected area with plenty of clean water
and consult a doctor immediately.
Remove the batteries from the product if it is
not in use for any length of time.
Make sure that the polarity is correct when you
insert the batteries. This is indicated in the bat-
tery compartment. The batteries can otherwise
explode.
Clean any light dirt deposits on the contacts of
the batteries or on the contacts of the product
with a dry, fluff-free cloth before insertion.
Please do not dispose of used batteries in your
household waste but take them to a designated
collection depot for special waste.
Assembly
Note: Before first use, please remove the protective
foil between the toilet lid and seat.
Remove the hinges 1 from the included pack
and insert them into the connection fittings on
the toilet seat
8 (see Fig. A).
Fit the plastic washers 4 over the threaded
rods of the hinges 1 (see Fig. A).
Place the toilet seat 8 on to the toilet bowl.
Guide the threaded rods of the hinges 1
through the openings at the back of the toilet
bowl (see Fig. B).
You can adjust the position of the toilet seat 8
by moving the threaded rods of the hinges 1
backwards and forwards inside the openings.
Press the fastening caps of the hinges over the
plastic washers
4 to fix the position of the toilet
seat 8 . Now fit the sealing cone washers 2
over the threaded rods of the hinges 1 and
fix them in place with the plastic nuts 5 . Now
fit the metal washers 3 over the threaded
rods of the hinges 1 and fix them in place
