5 GB/IE
Fitting
For transport, the article is delivered folded up.
To make the product ready for use, proceed as
follows:
Unfolding (Fig. A)
1. Loosen the bottom quick fastener (1).
2. Pull the lever (2) upwards and push the
handlebar (3) forward until it clicks in.
3. Secure the folding mechanism by locking the
lower quick fastener.
Fitting the handles (Fig. B)
1. Loosen the handles (4) from the brackets (5).
2. Press the lock buttons (6) on the handles
downwards and push the handles on the
T-bar (7) of the handlebar. The lock buttons
have to audibly lock into the drilled holes (8).
Adjusting the height of the handle
bar (Fig. c)
the handle bar is adjustable to three
different heights. the article may only
be used when the lock button is clicked
into one of the drilled holes provided
and the handle bar is subsequently
locked with the quick fastener!
1. Loosen the quick fastener (9) at the handle
bar.
2. Pull the handle bar (10) upwards, until the
lock button (11) clicks into one of the three
drilled holes (12).
3. Secure the handle bar by locking the lower
quick fastener.
Headset (Fig. D)
When the article is delivered, the headset is
pre-adjusted. Should the handle bar be too
loose or too stiff after a certain time, have the
headset adjusted by a specialist dealer or a
cycle shop.
Making the article ready
for transport (Fig. e)
1. Loosen the quick fastener at the handlebar,
press the lock button, push the handlebar in
fully, lock the quick fastener.
2. Press the lock buttons of the handles, pull the
handles out of the T-bar and fasten them on
the brackets.
3. Loosen the quick fastener and pull the bar
(2) upwards, push the handle bar direction
deck, until it clicks in. Lock lower quick
fastener.
Use
Driving, braking (Fig. F).
• Put one leg on the deck (13) and propel
yourself forward by regularly pushing off
with the other leg. The scooter can be
steered by moving the handlebar, moving
your weight and by a combination of both.
• For braking, step onto the brake plate (14).
Maintenance
changing the wheels (Fig. G)
Important!
Please observe the technical data.
Wheels with a different diameter can
change the handling characteristics
and may lead to danger for the user.
Never use wheels that cannot be fitted
properly. Never fit larger wheels than
the original wheels of the article.
The wheels wear. Wear is dependent on many
factors, such as the ground, the height and
width of the user, the weather conditions, the
material of the wheels and their hardness.
Therefore, it is necessary to change them from
time to time.
• Loosen the axle bolts (15) using two Allen
keys size 5.
• Pull out the axle bolts and remove the roll.
• Insert a new roll (16) and fasten it, using the
axle screws.
