6 GB/IE
Introduction / Safety Introduction
Car battery charger ULG 3.8 A1
Q Introduction
We congratulate you on the purchase of your new
device. You have chosen a high quality product. The
instructions for use are part of the product. They
contain important information concerning safety,
use and disposal. Before using the product, please
familiarise yourself with all of the safety information
and instructions for use. Only use the unit as described
and for the specified applications. If you pass the
product on to anyone else, please ensure that you
also pass on all the documentation with it.
Q
Proper Use
The UlTIMATE SPEED UlG 3.8 A1 is a battery
charger with a pulse trickle charge mode and is
suitable for charging and maintenance charging of
the following 6 V or 12 V lead rechargeable batter-
ies with wet cell or gel electrolyte:
• 6 V: with a capacity of 1.2 Ah to 14 Ah
• 12 V: with a capacity of 1.2 Ah to 14 Ah
• 12 V: with a capacity of 14 Ah to 120 Ah
You can also used it to regenerate completely dis-
charged batteries. The battery charger has protective
circuits to prevent sparking and overheating. Any in-
correct or improper use leads to loss of the warranty.
The manufacturer takes no responsibility for damage(s)
arising out of usage that is contrary to the instructions
laid down. The appliance is not meant for commer-
cial use.
Q Delivery Contents
Check the appliance and all accessories for damage
immediately after unpacking. Do not put a defective
appliance or parts into operation.
1 Charger
UlTIMATE SPEED UlG 3.8 A1
2 Quick / contact clamps (1 red, 1 black)
1 Operating manual
Q Component description
see Fig. A:
1 lED display (standby)
2 „6 V“ lED display „Mode 1“
3 lED display „Mode 2“
4 lED display „Mode 3“
5 lED display „Mode 4“
6 lED display „incorrect polarity / fault“
7 lED display „fully charged“
8 lED display „Charging process active“
9 Q Selection button „MODE“
see Fig. B:
10 Charging station
11 Mains lead
12 Mounting holes
13 „+“-Pole connection cable (red), incl. ring shoe
14 „–“-Pole connection cable (black), incl. ring shoe
15 „+“-Pole quick-contact terminal (red), incl. red
fixing screw
16 „–“-Pole quick-contact terminal (black), incl.
black fixing screw
Q
Technical Data
Input voltage: 220–230–240 V ~
50 / 60 Hz
Power consumption: 60 W
Reverse current*: < 5 mA (no AC input)
Nominal output voltage: 6 V / 12 V
Nominal output current: 0.8 A / 3.8 A
Charging voltage:
7.3 V or 14.4 V or 14.7 V
Charging current: 0.8 A ± 10 %
3.8 A ± 10 %
Battery type: 6 V lead-acid battery
1.2 Ah–14 Ah
12 V lead-acid battery
1.2 Ah–120 Ah
Temperature (min.): 0°C
Temperature (max.): 40°C
Housing protection type: IP 65 (dust-tight, protected
against water jets)
Safety class: II /
