5
IE GB
General description
See the front fold-out page for
illustrations.
Extent of the delivery /
Accessories
Carefully unpack the appliance and check
that it is complete.
- Mini compressor
- 4 Valve adapters
- Instruction Manual
Dispose of the packaging material cor-
rectly.
Overview
1 Carry handle
2 Manometer with air pressure
display:
(not calibrated)
- In bar: black scale
- In PSI: red scale
3 Vent holes
4 Mains cable
5 Cigarette lighter plug
6 On/off switch
7 Connection valve
8 Tensioning lever
9 Air hose
10 Valve adapters
a+b: For inflatable items
c: For balls
d: Adapter screw for bicycle
valve adapters
(Sclaverand or Dunlop)
11 Replaceable overload fuse
Technical data
Mini Compressor ............. UMK 10 A1
Rated voltage ............................ 12 V
Nominal current consumption .............7 A
Max. current consumption ................14 A
Maximum pressure ....................... 10 bar
Continuous operation ........... max. 5 min*
Air flow rate ............................. 35 l/min
Weight ............................approx. 1.7 kg
* Continuous operation: do not operate the de-
vice for longer than 5 minutes without interrup-
tion; then take a rest period of 20 minutes.
Technical and visual modifications may
be carried out due to further development
without prior notice. All dimensions, infor-
mation and statements provided in these
Operating Instructions are therefore subject
to amendment. Legal claims which are
based on the Operating Instructions can
therefore not be recognised.
Safety information
Symbols used in the instruc-
tions
Hazard symbols with in-
formation on prevention of
personal injury and property
damage.
Precaution symbol with information
on prevention of harm / damage.
Notice symbol with information on
how to handle the device properly.
