8
GB IE
4. Connection with valve adapter
(10):
- Push the respective valve
adapter into the connection
valve hole (7).
- Secure the valve adapter in
the connection valve (7):
push the tensioning lever (8)
towards the connection valve
(position
‚
).
- Plug the valve adapter into
the valve on the inflatable
item (remove the valve cap
on the inflatable item before-
hand if necessary).
Switching on/off:
5. Switch on the device:
On/off switch ( 6) in “I” position.
6. Switch off the device when the desired
fill pressure is reached:
On/off switch ( 6) in “0” position.
7. Disconnect the cigarette lighter plug
( 5).
Disconnecting the connection valve:
8. Connection without valve adapt-
er (10):
Open the connection valve (7)
tensioning lever (8) and remove
it from the valve on the inflat-
able item.
Connection with valve adapter
(10):
Remove the valve adapter from
the valve on the inflatable item.
Open the connection valve (7)
tensioning lever (8) and remove
valve adapter.
Air can escape from the valve on the
inflatable item when the connection
valve is released. Ensure that the
connection valve is removed quickly.
The manometer is not calibrated.
After inflating inflatable items on
which incorrect pressure may be
dangerous (e.g. car tyres), a spe-
cialist unit with a calibrated device
should therefore be visited.
Operation
Operating instructions
The device is not suitable for continuous
operation.
It has been designed to generate air pres-
sure not air volume.
• For large-volume items, please do not
operate the device for longer than 5
minutes without interruption, in order
to prevent overheating and damage to
the device. Then allow it to cool for at
least 20 minutes.
We recommend initially filling a large-
volume item with air in order to then
generate the desired pressure with the
device.
• Should you require a pressure greater
than 3 bar for a car tyre, do not use
the device for longer than 3 minutes
without interruption. Then allow it to
cool for at least 20 minutes.
Air pressure test
The device does not need to be
connected to the cigarette lighter in
order to measure the air pressure.
1. Connect the connection valve (7) (see
“Initial operation”).
2. Read off the air pressure on the ma-
nometer display (2).
3. Disconnect the connection valve (see
“Initial operation”).
