50 SMFB 2.1 A1
GB
Pairing/connecting/disconnecting hands-free set
and mobile phone
Before the hands-free set can be used it must be paired with a compatible
mobile telephone.
1) Check to make sure the mobile telephone is switched on.
2) Set the mobile telephone so that it scans for Bluetooth ® devices. A detailed
description of how to do this is to be found in the operating instructions for
your mobile telephone.
3) Position the hands-free set (main unit) and the mobile telephone so that
they are no more than 1 metre apart.
4) Press and hold the multifunction button 6 until the control lamp 7 lights
up alternately red and blue and two short beeps are heard. The hands-free
set is now in pairing mode.
5) Select the "SILVERCREST" hands-free set from the list of available devices
on the mobile telephone.
6) Enter the preset pass code "0000" and confi rm to pair the devices with
each other. The control lamp 7 fl ashes blue every 5 seconds and the
main unit switches to standby mode.
NOTE
► It may not be necessary to enter the pass code for some mobile telephones.
You can now use the hands-free set.
NOTE
► If pairing is not completed within 2 minutes, the main unit switches itself into
standby mode. You will need to repeat all of the steps.
Once the mobile phone has been paired with the hands-free set, proceed as
follows to connect the devices again.
1) Activate the Bluetooth function on your mobile phone.
2) Select "SILVERCREST" from the list of available devices.
3) Press the multifunction button 6 button on the main unit.
4) Confi rm the connection on your mobile phone.
