Assembly
CAUTION! DANGER OF FIRE! Assemble
and use the product on a fire-resistant surface only.
The following tools are required for
assembly:
7 x Open spanners (1 x 8 mm, 2 x 10 mm,
2 x 14 mm, and possibly 2 x 17 mm)
2 x Allen key
1 x Slotted head screwdriver (approx. 5 mm)
Follow these steps:
Fasten the saddle 33 on to the base plate 32
with the hexagonal socket head screws 35
and washers 34 (see Fig. A).
Fasten the handle 3 on to the mount 36 with
the projecting screw thread and the corresponding
nut (see Fig. A).
Note: Please bear in mind that the angle
grinder must be fitted with a suitable cutting
disc before assembly. It is not possible to
change the disc with the angle grinder installed
in the stand.
Now mount the angle grinder in the mount 36 .
Note: At this point, first check the size of the
handle thread of your angle grinder. It may be
M6, M8 or M10.
Then place the corresponding mounting bolts 9 ,
10 , 11 , washers 8 and matching nuts 12 , 13 ,
14 , distance pieces 15 , 16 , 17 and plastic
bushings 6 , 7 to one side, ready for use.
Insert the necessary plastic bushings 6 , 7
into the mounting pieces 18 , 38 (see Fig. B).
Note: Ensure that the size of the plastic
bushings 6 , 7 matches the required
mounting bolts 9 , 10 . Plastic bushings are not
required for mounting bolts M10 11 .
Screw the matching mounting bolt 9 , 10 , 11
through the rear mounting piece 38 (see Fig. B).
Fasten the rear mounting piece 38 in place by
tightening the corresponding size of nut 12 , 13 ,
14 on the mounting bolt 9 , 10 , 11 (i.e. by
turning it in the direction of the mounting piece 38 )
(see Fig. B).
Insert the adjustment screw 20 through the
bottom hole and the adjustment screw 1
through the top hole of the mount 36 . Note
that later the rubber buffers of these screws
must lie against the angle grinder housing.
Note: First insert these screws so that the rubber
buffers lie directly against the mount 36 .
Now push the plastic locating pieces 19 of the
mounting pieces 18 , 38 on to the guide of the
mount 36 (Figure B).
Then attach the mounting pieces 18 , 38
through the plastic locating pieces 19 with the
hexagonal socket head screws 31 in the
elongated holes in the mount 36 (see Fig. A).
Place the desired distance piece 15 , 16 , 17 on
the mounting bolt 9 , 10 , 11 and washer 8
on to the front mounting piece 18 (see Fig. D).
Note: The three distance pieces 15 , 16 , 17
are of different lengths. Choose the distance
piece 15 , 16 , 17 of the most appropriate length.
Note: Set the distance piece 15 , 16 , 17 so
that the cutting disc cannot come into contact
with the workbench / table below the base
plate 32 (see Figure E).
Screw the matching mounting bolt 9 , 10 , 11
through the front mounting piece 18 .
Fasten the front mounting piece 18 in place by
tightening the corresponding size of nut 12 , 13 ,
14 on the mounting bolt 9 , 10 , 11 (i.e. by
turning it in the direction of the mounting piece 18 ).
Now set the adjustment screws 1 , 20 so that
the angle grinder is aligned at right angles to
the base plate 32 and firmly attached to the
mount 36 .
After slightly loosening the hexagonal socket
head screws 35 , adjust the saddle 33 so that
the cutting disc of the angle grinder lowers into
centre of the slot provided in the base plate 32 .
Now attach the safety guard 5 . To do this
push the safety guard 5 on to the metal rod 2
and fasten it in place with the nut 4 (see Fig. C).
Now insert the metal rod 2 into the
corresponding opening in the mount 36 and
fasten it in place with the nut 39 and the
mounting bolt 40 (see Fig. C).
Always keep the angle grinder’s mains lead in
place using the clip 37 .
After assembly is complete, switch the angle
