Montageanleitung MA054 (de_en)
Assembly instructions
Einbaudose mit Schraubverbindung M12 EV400 Panel receptacle with screw connection
M12 EV400
Inhalt
Sicherheitshinweise....................................................................2
Notwendiges Werkzeug ............................................................3
Fronttafel bohren .......................................................................3
Montage der Einbaudose ..........................................................3
Montage des Schutzdeckels .....................................................4
Kabelanschluss ..........................................................................5 Content
Safety Instructions ......................................................................2
Tools required ............................................................................3
Drilling front panel .....................................................................3
Mounting the panel receptable .................................................3
Mounting the protective cover ..................................................4
Cable termination ......................................................................5
Anlieferzustand:
1 Einbaudose EV400, Bestell-Nr. 19.7902
Mitgelieferte Einzelteile:
2 Mutter, gesperrt (nicht mehr anziehen)
3 Mutter, vormontiert
4 PUR Ring auf Ringmutter montiert
5 Ringmutter
6 U-Scheibe
7 U-Scheibe
8 Federscheibe
9 Mutter
10 Schutzdeckel DE16N, Bestell-Nr. 14.5165
11 4x M3 Schrauben, Muttern und U-Scheiben Article supplied:
1 Panel receptacle EV400, Order No. 19.7902
Components supplied with article:
2 Nut, locked (do not tighten further)
3 Nut, pre-mounted
4 PUR ring, mounted on ring nut
5 Ring nut
6 Washer
7 Washer
8 Spring washer
9 Nut
10 Protective cover DE16N, Order No. 14.5165
11 4x M3 screws, nuts and washers
