Advanced Contact Technology
6 / 8
www.multi-contact.com
17
18
Demontage
Disassembly
(ill. 17)
Fьr Ш 1 / 1,6 / 3 und 6 mm
Kontakte
Für die Wartung (nach 10‘000 Steck-
zyklen) Kontakte mit entsprechendem
Werkzeug entfernen
(ill. 17)
For contacts Ø 1 / 1,6 / 3
and 6 mm
For maintenance (after 10’000
matings) remove the contacts from
the contact carrier with the corre-
sponding extraction tools�
(ill. 18)
Fьr Ш 10mm Kontakte:
Sicherungsring mit der Siche-
rungsringzange (ill� 4) entfernen�
(ill. 18)
For Ø 10mm contacts:
Remove the circlip with the circlip
pliers (ill� 4)
