MA101 (de_en)
Montageanleitung MA101 (de_en)
Assembly instructions
Halter für Verbindungsleitungen LKH
Bestell-Nr. 25.0001 Connecting lead holder LKH
Order No. 25.0001
Inhalt
Sicherheitshinweise....................................................................2
Montage ....................................................................................4 Content
Safety Instructions ....................................................................2
Assembly ...................................................................................4
Pos. Typ
Type Bezeichnung
Description Bestell-Nr.
Order No.
1 LKH-S
1 Klemmschiene
1 clamp rail
25.5004
2 LKH-Sch
2 Holzschrauben
2 wood screws
25.5008
3 LKH-D
2 Dübel
2 wall plugs
25.5009
4 LKH-BSch
2 Blechschrauben
2 sheet metal screws
25.5010
5 LKH-A
1 Ankerschiene
1 bracket holder
25.5001
6 LKH-K
21 Kunststoffkonsolen
21 plastic hooks
25.5003
7 LKH-B
21 Befestigungsbolzen
21 fi xing bolts
25.5005
