PRAKTICA CDV 1.0 - Handbuch (Seite 9)

2
16
17
10
13 14 15
11
12
10. Suction hole
11. Battery cover
12. Speaker
13. SD card slot
14. DC socket
15. Mic
16. Lens
17. Infrared lamp
User manual
Power supply:
use lithium battery
Charging way: connect to car charger adapter
Note: when use the lithium battery, you need press power button to turn on or
turn off your DVR.
connect 12V/24V car charger adapter
When auto starting, DVR begin to recording automatically, power cut will stop
recoding and save the file to the memory.
Note: just 5V output is available.
A
B
Operation steps
Insert a SD
memory card
correctly into the
SD/MMC card
slot. Mounting bracket
correctly into the
holder and then
put the suction cup
in a suitable
place, adjust the
location and
direction. Use 5V output
attaching plug
(car charger
adapter), plug in
the DC 5V
connector. Hold the
“ON/OFF” button
for 3 seconds
to turn on your
camcorder,
setting specific
parameter,
please refer to
this manual as
below.
13
The first step:
Insert a SD
memory card The second step:
Mounting bracket The third step:
plug in the car
charger power The fourth step:
power on
(Class 4 or higher
are required(
