Blue must be connected to the terminal
marked with the letter N or coloured black.
Blue must be connected to the terminal
marked with the letter or coloured black.
Brown must be connected to the terminal
marked with the letter or coloured red.
If the power cord is damaged, it must be
replaced by one with the same reference
number, only available from an authorised
service centre.
The manufacturer will not be held res-
ponsible if correct instructions have not
been carried out.
Positioning and levelling
The washing machine has adjustable feet
and can be leveled by screwing the feet in
or out as required (Fig. 7).
If the washing machine is sited under a
work surface or between units check the
dimensions given in (Fig. 8).
Make sure that the pipes at the rear are not
bent when fitting otherwise the machine
may malfunction.
Washing machines with
decor panels
Decoration
Our machines with decor doors panels can
be fitted to match you kitchen. The panels
should not be thicker that 5 mm. and are fit-
ted as follows.
1/ Take the door off the washing machine
by removing screws of holding hinges
B (Fig. 9).
2/ Remove the lower protective frame C
by removing screws D (Fig. 9).
3/ Remove the panel supplied with the
washing machine.
4/ If the new decorative panel is 3 mm. or
more put this in place of the existing
panel.
5/ Replace the frame and refit the door.
Adjusting the door height
The decor door can be adjusted in height to
line up with existing kitchen units. The lower
part of the door and the lower frame are
devided into seven sections each of 10 mm.
height. By removing sections the height can
be adjusted between 10 and 70 mm. (Fig.
10). Change the height as follows.
1/ Take the door off the washing machine
by removing screws B from hinges A
(Fig. 9).
2/ Remove lower frame C by removing
screws D.
3/ Remove panel supplied with machine.
4/ Adjust the height of the door and lever
frame to suit your requirements by
removing the adjustable sections.
5/ Refit the door.
Reversing the door
The decor door can be reversed for left or
right hand opening.
1/ Remove screws B from hinge A and lift
off door (Fig. 9).
2/ Remove lower frame by undoing
screw D.
3/ Remove decor panel.
4/ Take off hinges (Fig. 12).
5/ Remove automatic lock F from door by
releasing screws from door. Gently
move lock to release.
6/ Take out locking arm H (Fig. 12) by
releasing screw and moving to one
side.
7/ Remove protective cap J.
8/ Refit auto lock protective cap, hinges in
their new positions.
9/ Replace door frame and panel and refit
door.
Optional worktop
If your wish to remove your washing machi-
ne worktop when fitting under a kitchen
work surface an optional protecting the
working of the machine, only available from
an authorised service centre.
This top is fitted as follows.
1/ Remove existing worktop (Fig. 13) by
releasing screws A.
2/ Remove worktop support (Fig. 14).
3/ Fit protective top (Fig. 15).
