Information
Manual description
In order to help you understand this manual
we have included in the back of the book
some illustrations. These illustrations
should be related to when reading the text.
Rating plate (Fig. 1)
This plate is fixed on the front of the applian-
ce. The plate shows the supply details of the
appliance and must be consulted before
connecting to the electricity supply.
Electrical connections
These should be carried out by qualified
competent persons. The appliance should
only be used on the voltage shown on the
rating plate.
This washing machine complies with the
provisions of the directive 87/308/EEC of
the European Community concerning
radio interference.
On built-in washing machines, the mains
plug must be accessible after installation.
Unpacking and unblocking
Unpacking
Remove the transport wrapping and
polystyrene protection pieces.
Unblocking (Fig. 2)
IMPORTANT: The transit bolts must be
removed before using your washing
machine.
1/ Unscrew the screws (A) which hold the
plates (B) to the back of the machine.
2/ Unscrew the blocking bolts and remove
them.
3/ Recover the holes with the plates (B).
4/ Keep the blocking bolts in case you
transport your machine at a future date.
Dimensions
Before finally installing your washing
machine consult (Fig. 3) in which the mea-
surements of the appliance are given.
Connecting to the water supply
Inside the drum you will find a water inlet
pipe.
1/ The angled end of the water pipe fits to
the washing machine water valve (Fig. 4).
2/ The straight end fits to the supply tap.
which should have a 3/4"B.S.L. thread
(Fig. 5).
Turn the pipes to the correct position and
tighten the nuts.
The washing machine is to be connected
to the water supply network using the
new supply pipes provided with the
appliance. The old water supply pipes are
not to be used.
For correct functioning of the washing
machine, the water network pressure
must be between 0.05 and 1 MPa (0.5 - 10
Kgrf/cm
2 ).
Connecting the drain pipe
The drain pipe must be hooked into a stand
pipe of 32 mm. (1 1/4") minimum diameter.
The stand pipe should be between 50 and
70 cm. above loor level and never more
than 90 cm. Avoid folds and bends in the
drain pipe and mak sure that the elbow is
well fitted into the stand pipe to avoid any
risk of the pipe falling out.
Connecting the electricity
This machine should only be connected to
the voltage shown on the rating plate.
WARNING: THIS APPLIANCE MUST BE
EARTHED.
Important-The wires in the mains lead are
coloured in accordance with the following
code:
Green & yellow - Earth
Blue - Neutral
Brown - Live
Ensure the fuse in your plug or fuse box is
13 or 15 amp. capacity.
As the colours of the mains lead may not
correspond with the markings in your plug
proceed as follows.
Green & yellow must be connected to the
terminal marked with the letter E or by the
earth symbol or coloured green or green
and yellow.
