OPERATION INSTRUCTIONS
Stripping Tool
BWZ 5-02
Technical data:
Stripping using the stripping block
Stripping dimension of AXING
-line premium
antenna sockets 8/13 mm
Stripping dimension of Axing compr. connector* 7/6 mm
Cables that can be used: SKB 88-xx
SKB 89-xx
SKB 395-xx
SKB 92-xx
SKB 93-xx
and cables with a dielectric diameter of 4,7 ± 1 mm
Stripping of cables 2,7-6,7 mm Ø
Cutting blade for coaxial cables max. 8 mm Ø
*CFS 93-xx/CFS 97-xx
Note: Not suitable for cables with steel wire or stranded
steel wire
Risk of cutting and crushing!
Do not place your fingers between the blades or
jaws of the stripper!
