- 55 -
10
Mapping - channel 9
The mapping channel split the circular patterns from pattern channel to different LED segments.
Pattern mode - channel 10
Is an overall channel for mapping, pattern und pattern speed. The pattern mode controls if a
effect is fade, switch, static or a pixel flash. Also a macro area helps fast programming.-
Pattern / Pattern speed - channel 11/12
This channel provides 7 increasing, decreasing and random patterns and can controlled by
speed and direction with the pattern speed channel. Without mapping channel, the patterns run
in circular form. The pattern mode as overall controls the kind of running.
Color spread - channel 13
This channel generates an indexable and rotatable color spread on the foreground color of the
running effect.
Sparkle / Sparkle speed - channel 14/15
This is the name given channel of the Sparx10. This channel offers a unique sparkling effect ad-
ditional with dimmer and zoom channel. The beam is splitted to the ground colors of the beam
depending on the intensity of the channel value. That means full colors get in sparkling forms to
fade in and fade out effects. A mixed color is splitted to the ground colors.
Examples for use of channels 9 to 15
In the following table you will find some configurations of the channels to create patterns and
effects. This table you can use as a template to create your own patterns and effects.
Mapping
CH09
Pattern
Mode
CH10
Pattern
CH11
Pattern
Speed
CH12
Glow
R
CH21
Glow
G
CH22
Glow
B
CH23
Main
R
CH25
Main
G
CH26
Main
B
CH27
Pattern
R
CH39
Pattern
G
CH30
Pattern
B
CH31
Sparkle
CH14
Sparkle
Speed
CH15
000 001 001 026 000 000 000 000 000 255 255 000 000 000 000
080 000 005 013 000 000 000 000 000 255 255 108 000 000 000
079 128 001 004 000 255 000 000 000 255 255 000 000 000 000
086 004 004 004 000 000 000 000 000 066 255 255 171 000 000
027 001 001 026 000 000 000 000 000 255 255 000 000 000 000
033 129 004 005 255 255 171 000 000 255 255 000 000 000 000
086 006 004 008 000 000 000 000 000 080 255 255 171 000 000
110 012 001 000 000 000 000 000 000 255 255 255 171 000 000
111 012 001 008 000 000 000 000 000 255 255 255 171 000 000
000 000 000 000 000 000 000 255 000 255 000 000 000 201 010
