23
JB-lighting Lichtanlagentechnik GmbH Sallersteigweg 15 D-89134 Blaustein Telefon +49 (0)7304-9617-0
To adjust the personal setting of the Varyscan P6 use keys located on the control panel.
Functions see menu on the following page.
To enter the menu press MENU key one time.
Use keys - and + to move within the menu.
Use key ENTER to select the function and to recall the next menu section
To escape press key MENU
3. Control panel
2.5 Installing a plug on the power cord
Install a plug like described in chapter 2.2.
Connected load: Voltage 230Volts, frequence 50Hz, power 900VA (3,9 Amps)
Use a power supply of at least 960VA (4,2 Amps) per unit, as the fixture need more
power during the process of powering up.
Connect the fixture to a proper installed grounded system only. If any doubts
on the electrical installations occur, consult a qualified electrician.
In case of damages occuring due to a not propper installed electrical system,
warranty claims will be invalidated.
Don´t use fixtures when top cover is not fixed properly. Contact with electronical
parts can result in risk for life.
Connect fixture only after assuring that the electrical installation fits your demands.
If any doubts occur consult a qualified technican!
(Electrical shock 5000V)
Varyscan P6
900 VA
230V 50Hz
CAUTION!
Disconnect mains
before opening
