Seite 4
30
10
20
12
3
9
6
10
1
2
3
7
8
9
15
60
30
45
21
III
30
10
20
12
3
9
6
10
1
2
3
7
8
9
15
60
30
45
III
III
21
Push-button B
Push-button A
Adjusting the chronograph
hands to zero position
Example:
One or several chronograph hands are not
in their correct zero positions and have to be
adjusted (e.g. following a battery change).
Pull out the crown to position III
(all 4 chronograph hands are in their
correct or incorrect zero position).
Keep push-buttons
A and B depressed
simultaneously for at least 2 seconds
(the centre stop-second rotates by
360°
corrective mode is activated).
Centre stop-second
1
⁄
10
second counter
Minute counter
Hour counter
Adjusting the centre stop second
Single step
A
1 x short
Continuous
A
long
Adjusting the next hand B
Adjusting the
1
⁄
10
second counter hand (position 6h
)
Single step
A
1 x short
Continuous
A
long
Adjusting the next hand B
Adjusting the minute counter hand
and the hour counter hand
(mechanical coupled)
Single step
A
1 x short
Continuous
A
long
A
B
A
III
III
Returning the crown to position I
Termination of the chronograph hands
adjustment (can be carried out at any time).
B
A
