114
Vorderseite
Lesen Sie hinsichtlich der hier nicht erklärten Tasten die in Klammern ( ) angegeben Seiten.
q
e r
y
t
i
u
Q6
o
w
Q0
W1
W0
Q7
W2
Q8
Q9
Q2
Q1
Q4
Q3
Q5
Bezeichnung und Funktionen der Teile
q
Netzanzeige (STANDBY) ·················································· (
C 5)
GNetzanzeigestatus im Standby-ModusH
• Normales Standby : Rot
• Wenn “HDMI Steuerung”(
)
auf “EIN” eingestellt ist : Orange
)
auf “EIN” eingestellt ist : Orange
w
Netzschalter
(ON/STANDBY) ································································· (
C 5)
Schaltet das Gerät ein und aus (Standby).
e
Kopfhörerbuchse (PHONES)
Wenn der Kopfhörer an diese Buchse angeschlossen ist, ist kein
Ton mehr aus den angeschlossenen Lautsprechern zu hören.
HINWEIS
Zur Vermeidung von Gehörschäden sollte die Lautstärke nicht
übermäßig hoch eingestellt werden.
Q3
PURE DIRECT-Taste ································································ (
)
Q4
ONE TOUCH PLAY-Taste ·················································· (
)
Q5
iPod/USB-Anschluss ······························································· (
)
Q6
VOLUME-Knopf ······································································· (
)
Q7
PURE DIRECT-Anzeige ···························································· (
)
Q8
Hauptlautstärkeanzeige
Q9
Display ···················································································· (
)
W0
Fernbedienungssenso ··························································· (
)
W1
M-DAX-Anzeige ······································································· (
)
W2
INPUT SELECTOR-Knopf ························································ (
)
r
SETUP MIC-Buchse ··························································· (
)
t
SURROUND MODE-Tasten ············································· (
)
y
STATUS-Taste ····························································· (
)
u
DISPLAY-Taste ··································································· (
)
i
MENU-Taste ································································· (
)
o
ENTER-Taste ···················································· (
)
Q0
Pfeiltasten (
uio p) ·································· (
)
Q1
RETURN-Taste ····························································· (
)
Q2
BAND-Taste ······································································· (
)
