Revox Scala 120 - Handbuch (Seite 11)

Scala 120 Revox
9
Unpacking & Installing
The Scala 120 has a glass pedestal
that is delivered with the speaker,
packed separately. This has to be
screwed to the speaker before you
start using it, in order to ensure
sufficient stability in operation. To
do this, working with another
person, lay the housing carefully on
its back onto a soft, padded surface,
as shown in the picture below. Now,
using a Torx TX20 screwdriver,
screw the glass pedestal to the
speaker using the four screws
provided. The screws should only
be hand-tightened. On no account
should a powered screwdriver be
used as the high torque that this
would create, may cause the glass
to crack.
Now the protective film can be
removed carefully from the top of
the speaker.
We recommend that you keep the
packaging material in case you
should need it in the future to
transport the speakers.
Speaker grille
The front grille on the Scala 120
should not be removed! The reason
for this is that during manufacture, it
is aligned exactly to the curve of the
housing edge and is elastically
mounted in such a way as to
prevent vibrations. There is also a
risk that the surface of the housing
will be damaged if the grille is
removed and replaced.
