Eneo VKCD-1338 - Handbuch (Seite 48)

48
5. Connection
5.1 Connecting to Monitor and Power
Function Terminal Colour Remark
1 Video output Yellow .0 Vp.p
2 Power input Red VDC (9V~5V), max. 4.8W/400mA
• Connect the video-out jack to the video-in jack
of the monitor.
• Connect the power adapter to the power input
connector.
• Use VDC
power source
• Use the power rated at least 400mA (VDC)
GND
Video (yellow)
Power - VDC
(red)
Video Output
