Eneo VKC-1382/IR-316 - Handbuch (Seite 36)

36
6. Specifications
Type VKC-1382/IR316
Art. No. 92697
System Day&night
Video standard CCIR/PAL
Sensor size /3”
Imager CCD, Sony Super HAD II Interline Transfer
Active picture elements 440,000, (H) 75 x (V) 58
Synchronization Internal
Signal-to-noise ratio 5dB (AGC OFF)
Horizontal resolution 600 TVL
Sensitivity (at 50% video signal) 0.4 Lux, (coulor), 0.07Lux (B&W) at F. (measured)
Automatic electronic shutter (ESC) /50 ~/0,000sec.
Manual electronic shutter (MES) /50 ~/0,000sec.
Low speed shutter yes, Automatic, ~5 Fps., ON/OFF switchable
Automatic gain control (AGC) Low, High, OFF
Digital Noise Reduction (DNR) yes, 3D / SSNR3 (Selected Super Noise Reduction)
Flickerless function yes
Mirror function Horizontal, vertical
White balance ATW, outdoor, indoor, manual, AWC (Hold)
Backlight compensation BLC, HS BLC (eclipser), ON/OFF switchable
Wide Dynamic Range (WDR) yes, SSDR (Selected Super Dynamic Range)
Brightness Selectable
Sharpness correction ON/OFF switchable
IR cut filter Switchable
Video outputs Composite (CVBS)
Lens type Varifocal
Lens F./3.5~6 mm
Focal length 3.5 mm - 6 mm
PTZ support no
Digital zoom x~6x
Horizontal angle of view 70° - 7.5°
Iris control DC
MOD (Minimum object distance) 0.5 m
Filter screw size Not available
Illumination Infrared, 70x LED’s 850nm. Due to an integrated light sensor the LED
illumination will be switched ON/OFF, depending on environmental
illumination conditions
Illumination range approx. 80m (at a good light reflexion and 40% video signal)
Menu languages German, English, French, Spanish, Italian, Czech, Romanian, Turkish,
Danish, Portugese, Polish, Serbian, Russian, Chinese
OSD function control Day&night, AGC, WDR (SSDR ~5), BLC/HLC, shutter control, white ba-
lance, colour intensity, DNR (SSNR3 ~3), DIS, brightness, sharpness,
H/V flip (mirror picture), digital zoom, motion detection, privacy zones,
text, language, interface protocol, default
