Optional Accessories
The optional accessories currently available can be found on our Homepages: www.videor.com and
www.eneo-security.com
Type VKC-1424-36 VKC-1424-22 VKC-1424-12
Art. No. 92718 92754 92755
OSD function control AGC, DNR, colour/B&W, motion detection, WDR/BLC, privacy zones, white
balance, text, effect (freeze, pos./neg., flickerless), sharpness correction,
shutter control, brightness
Text display title and camera ID
Motion detector yes, 3 zones, ON/OFF switchable
Privacy zones masking 6 zones masking, ON/OFF switchable
Serial interfaces RS-485
Serial interfaces protocols Pelco D, Pelco P, Visca
External adjustments menu, zoom and focus, switch for cable length adjustment
External connections RS-485, alarm output, external day&night switching, video (BNC), AD key
Temperature range (operation) -0°C ~ +50°C
Housing material metal / plastic
Integrated wall mount no
Window heater no
Vandalism resistant no
Protection rating n/a
Alarm inputs –
Alarm outputs
Supply voltage VDC (+/-0%)
Power consumption 4.0watts max. 3.6watts max.
Dimensions see drawings
Weight 370g 340g 80g
Parts supplied camera, manual
Certificates CE
