Always switch off and disconnect power cord when not in use
Controls the boost and cut of the low-frequency response of the pre-amplifier.
Selects the mid-frequencies (100Hz to 1KHz) to be cut or boosted in conjunction with the paramid / Lo-paramid level control.
To access low mid-frequencies turn the frequency control anticlockwise, to access higher mid frequencies turn the frequency
control clockwise.
Sets the level of boost or cut applied to the frequency set by control. For frequency-boost turn the control clockwise. For
frequency-cut, turn the control anti-clockwise.
Selects the Hi mid-frequencies (400Hz to 4KHz) to be cut or boosted in conjunction with the Hi paramid level control.
To access low Hi mid-frequencies turn the frequency control anticlockwise, to access higher Hi mid-frequencies turn
the frequency control clockwise.
Sets the level of boost or cut applied to the frequency set by control. For frequency-boost turn the control clockwise.
For frequency-cut, turn the control anti-clockwise.
Controls the boost and cut of the high-frequency response of the pre-amplifier.
This gives a high mid boost to the signal with more character and “presence" than just turning up the Treble.
Allows the on-board limiter to be defeated if desired. With the switch in the out position the limiter is engaged. The limiter is
automatically triggered at high-output levels and is designed to prevent power-amp distortion at high-output levels. When the
limiter is automatically triggered the LED lights up to indicate the limiter is active. It is possible to have the limiter engaged but
not have the LED active. The limiter monitors both power-amp clipping and speaker load so it automatically registers the
cabinet-impedance and sets itself accordingly.
Sets the overall listening level of the amplifier.
Activates the on-board high frequency horn.
XLR socket for direct-injection of the amplifier signal to a mixing-desk or additional power-amplifier. The XLR socket provides
a balanced low-impedance output-signal from the pre-amplifier taken before any tone correction.
Indicates power is connected and the amplifier is switched on.
Main power on/off switch.
