28 PHKSU 710 A1
GB
CIRCULAR SAW PHKSU 710 A1
Introduction
Congratulations on the purchase of your
new product. You have decided to
purchase a high-quality product.
The operating instructions are part of this product.
They contain important information on safety, use
and disposal. Before using the product, familiarise
yourself with all operating and safety instructions.
Use this device only as described and only for the
specifi ed areas of application. Please also pass these
operating instructions on to any future owner(s).
Proper use
The circular saw (hereinafter “device”) is designed
for longitudinal, cross and mitre cuts in fi rmly
supported solid wood, chip board, plastics and
lightweight construction materials. It is also for
sawing lightweight and non-ferrous metals such as
copper piping or aluminium profi le. Please note that
the pre-assembled saw blade with its fl at teeth and
alternating chamfer makes it possible to achieve
a rough sectional cut at high resistance levels.
Any other uses or modifi cations to the device are
deemed to be improper usage and may result in
serious physical injury. Not for commercial use.
Depicted components
Safety lock-out
ON/OFF switch
Locking screw
Base plate
Wing screw
Guide fence slot
Auxiliary handle
Spindle lock button
Guide fence
Clamping fl ange
Clamping screw / plain washer
Lower blade guard
Release lever
Saw blade
Chip ejector
Vacuum adapter for dust extraction
Cutting depth scale
Allen key
Package contents
1 Circular saw
1 Guide fence
1 Vacuum adapter for dust extraction
1 Allen key
1 operating manual
Technical details
Nominal power input: 710 W
Rated voltage: 230 V ∼ 50 Hz
Idle speed: n
0
= 4.300 min -1
Saw blade: Ø 110 mm x 1.65 mm x
Ø 20 mm, 24 teeth
Max. cutting depth: Wood 35 mm, plastic
35 mm, exclusively light-
weight metal/non-ferrous
metal such as copper pipe
or aluminium profi le up to
max. 8 mm
Protection class: II /
Noise and vibration information:
Noise measurement determined in accordance
with EN 60745 The A-rated noise level of the
electric tool is typically:
Sound pressure level: 90.09 dB(A)
Sound power level: 101.09 dB(A)
Uncertainty K: 3 dB
Wear ear protection!
Evaluated acceleration, typically:
Hand/arm vibration a
h
= 3.808 m/s 2
Uncertainty K = 1.5 m/s 2
