40 GB
Commissioning / Possible applications / After initial use
Step 1:
Insert the selected tool into the intake of the com-
pressed air multitool. You may adjust the accessory
to the desired alignment in 30° increments using
the 4 setting pins (see Fig. C).
Step 2:
First place the washer
5 onto the accessory (see
Fig. D) and then place the tension ring 6 over it
(see Fig. E).
Step 3:
Now take the Allen screw
7 and tighten using the
included Allen key 1 . Use the counter wrench 18
to fix the appliance while tightening the Allen
screw
7 (see Figs. F and G). Your accessory is
now correctly attached.
ATTENTION! Verify the screw is tight and has
no play. The loose accessory will otherwise
pose a risk of injury during use.
ATTENTION! During use be sure only to bring
the equipment into contact with the material to
be processed once it has reached sufficiently
high speed. Putting the equipment on the mate-
rial and then switching it on is dangerous and
may result in injury.
Verify the equipment is correctly connected
and the connecting hose properly seated.
Use the pressure applied to the trigger to control
the speed of the equipment. Hold the equipment
with both hands during use to allow for safe
control of the tool without slipping (Fig. K).
Note: Applying light pressure to the surface
to be worked on will suffice.
Pull the trigger 4 to start the equipment.
Release the trigger 4 to stop the equipment.
Possible applications
Using the sanding attachment
(see Fig. I, J)
Attach the sanding attachment 12 as described
in Chapter “Attaching accessories”, but without
using the washer
5 .
Select the correct sandpaper for your applica-
tion (coarse / medium / fine)
2 , 3 , 4 and
press onto the hook-and-loop pad of the sand-
ing attachment.
Be sure the sandpaper is centred and pro-
trudes as little as possible on all sides.
Using the scraper attachment
(see Fig. K)
The two scraper attachments 13 , 14 can be
used to remove stubborn materials from surfaces.
Use either the straight
13 or the curved 14
scraper attachment. The latter with its curved
blade ensures there is some distance between
the material and the equipment.
Using the saw attachments
(see Fig. L)
Use the included saw attachments ( 15 / 16 / 17 )
to cut up to 3 cm deep into wooden materials.
The manufacturer prohibits cutting any other
materials as the attachments are not designed
for this purpose, thus posing the risk of dam-
age or injuries.
When using these attachments pay particular
attention to handling the equipment safely with
both hands. Never apply high pressure or posi-
tion your hand where it can easily slip off.
CAUTION! DANGER WHEN
SAWING! Keep hands away from
the area of the saw blade. Do not
reach below the work piece and never adjust it
with the hand within the area of the cut. Contact
with the saw blade may result in injury.
After initial use
Once the task has been finished the equipment
must be disconnect from the compressed air supply.
Briefly activate the trigger on the equipment to
release any compressed air remaining in the
equipment.
First pull back on the lock 10 (see Fig. M).
Then remove the coupling 11 (see Fig. N).
After initial use / Maintenance / Cleaning and care / Troubleshooting
