GB / IE / CY - 4
IE GB
Danger Deflagration hazard!
Flammable liquids, which are poured onto the smoul-
dering coals, result in darting flames or deflagration.
– Never use flammable liquids such as petrol or ethyl alcohol.
– Do not place any pieces of charcoal soaked in firestarter liq-
uid on the hot coals.
Danger Danger of poisoning!
Carbon monoxide is produced when burning char-
coal, barbecue briquettes etc. This gas is odourless
and can be fatal in enclosed rooms!
– Only use the grill outdoors.
Danger Health hazard!
Do not use any dye solvents or thinners to remove
stains. They are hazardous to health and must not
come in contact with food.
Danger Dangers for children!
Children can become trapped in the packing film
when playing and suffocate.
– Do not allow children to play with the packing film.
– Make sure that children do not put small assembly parts in
their mouth; they could swallow them and choke.
Danger Risk of injury
Some areas of the grill and individual parts have
sharp edges.
– Handle the individual parts of the grill will care to prevent ac-
cidents and/or injury when assembling and using the grill. If
necessary, wear protective gloves.
– Do not set up the grill close to entrances or highly frequented
areas.
– Always be very careful when grilling. If you are distracted, you
may lose control of the device.
– Always be attentive and pay attention to what you are do-
ing. Do not use the product if you are not concentrated or
tired and/or under the influence of drugs, alcohol or medica-
tion. Even a single moment of inattentiveness when using the
product may result in serious injury.
Attention Risk of damage!
Any screwed connections may gradually loosen dur-
ing use and affect the stability of the grill.
– Before use, always check that the screws are secure. If nec-
essary, tighten all screws again in order to ensure that the
grill has a stable position.
Attention Risk of damage!
Do not use any strong or abrasive solvents or scouring
pads as they may attack and scratch the surfaces.
Assembly
Preparation
Danger Risk of injury!
Failure to observe the instructions may result in prob-
lems and risks when using the grill.
– Always follow all assembly instructions provided.
1. First completely read through the assembly instructions.
2. If necessary, have another person assist you.
3. Take enough time for the assembly and clear a work area of
two to three square meters.
4. Lay out any required tools so that they are within reach.
Small parts such as handles may come preassembled.
Required tools
1 x cross-slotted screwdriver
Assembling the grill
1. See Fig. 1:
Mount the supporting column (a) on the base plate (b) with 2
screws (1).
2. See Figure 2:
Run the screw (5) through the knob (4).
Secure the vent grate (3) on the front supporting column (c)
with the nut (2) and the knob (4). Do not tighten the screwed
connection excessively, the grate must be able to open and
close.
3. See Fig. 3:
Place the supporting column (c) on the base plate (b) such
that it interlocks with the rear supporting column.
Mount the supporting column (c) on the base plate (b) with 2
screws (1).
4. See Fig. 4:
Insert the ash collector (d).
5. See Fig. 5:
Place the fire trough with the lid (e) in the supporting column
and secure it with 4 screws (1).
6. See Fig. 6:
Secure the handle (f) on the lid with the two washers (6) and
the long screws (1).
7. See Fig. 7:
Fold up the side parts (h).
Connect the side parts with the hood. For this, use the con-
necting sheet (g), M5 nut (2) and screw (1).
8. See Fig. 8:
Insert the ash plate (i).
9. See Fig. 9:
Mount the two handles (l) on the grill rack (k) and hook in
the grill rack using the handles.
S
A
–
•
B
W
us
U
D
an
–
–
–
–
–
–
1.
2.
3.
4.
5.
6.
7.
8.
9.
