6

FTKG 29 A1

GB

IE

Step 2

♦

Screw the support legs

10

to the ﬁ rebowl

7

using bolts M6 x 30

B

and

washers Ø6 x 25

E

.

♦

Secure the ventilation plates

2

to the ﬁ rebowl

7

using screws M5 x 10

C

,

washers Ø6 x 12

G

, spring rings Ø5

H

and nuts M5

I

.

Step 3

♦

Secure the bracket closures

8

and the brackets

9

to the ﬁ rebowl

7

using

bolts M3x10

D

and nuts M3

J

.

10

B

2

7

E

G

H

I

C

8

9

7

D

J
