an adequate distance away from the vehicle
when the hydraulic vehicle jack is in use.

Never change the setting of the safety valve 4 .
It is preset to the correct setting in the factory
and must never be readjusted later.

Do not use the hydraulic car jack if the sealing
(safety valve
4 ) is damaged.

Before using the vehicle jack, the user must be
made familiar with the device by an experi-
enced person. The pump force and the trans-
ferred force are equal to approximately 350 N.

If the markings on the product are damaged
enough so as to be illegible then the vehicle
jack must not be used until the markings are
renewed.

No modifications may be carried out to the
hydraulic bottle jack. Any physical modifica-
tion of the device and its compliance with
EN 1494 / A1: 2008.

The applied force when using the vehicle jack
must not exceed 350 N. The equates to a
force on the lever of approximately 35 kg.

CAUTION! RISK OF SHEARING
AND CRUSHING INJURY! Keep
your fingers away from the area of
the lifting handle socket 3 while pumping.
Failure to observe this advice may result in
shearing and crushing injury.
The operating temperature of the hydraulic oil
of this equipment is between -20 °C to +40 °C.
Do not use this equipment in rooms exposed to
fire hazards, where flammable or explosive
vapours or dusts may be present (e.g. in stables,
barns or paint shops).
Only use this device to lift and lower the vehicle,
not to keep the vehicle in a lifted position. Do
not move it whilst raising or lowering.
Do not use the equipment if oil leaks are present.
After use return all parts used into their original
position. Have the hydraulic oil or oil pump
replaced by a professional if the parts can no
longer be moved.
 Use
 Raising the vehicle
CAUTION! RISK TO LIFE! Check that the
vehicle jack and axle stands are in an undamaged
condition before you use them. Ensure that the
hydraulic vehicle jack is used only in combination
with axle stands. Have your axle stands to hand be-
fore raising the vehicle. If you do not use axle stands,
the vehicle may tip over and cause a risk to life.
Follow these steps:

Ensure that the rod 7 is fully lowered and the
extension screw 2 is completely screwed in
before you put away the vehicle jack.

Place the hydraulic vehicle jack in the desired
position. In choosing the position, observe the
provisions of the owner‘s manual for your vehicle.

If necessary screw out the extending screw 2
until it comes into contact with the underside of
the vehicle (Fig. B).

Connect the rod 7 to the lifting handle 6 to
extend the lifting handle.

CAUTION! RISK OF SHEARING
AND CRUSHING INJURY! Keep
your fingers away from the area of
the lifting handle socket 3 while pumping.
Failure to observe this advice may result in
shearing and crushing injury.

Guide the end of the lifting handle 6 into the
lifting handle socket 3 and pump the vehicle
up to the desired height (Fig. C).

Place the axle stands under the designated
jacking points under the vehicle.

Relieve the load from the vehicle jack by plac-
ing the rod
7 with the oval opening on to the
release valve 5 , then turning the rod 7 slightly
anticlockwise before turning it back immediately.
The support plate
1 drops slightly and the
vehicle is held on the axle stands.
 Lowering the vehicle
DANGER TO LIFE! Check that no person or
object is under the vehicle before you lower it.
