8 GB/IE
(Fig. C) until the support plate 1 is fully
lowered.

Screw the extension screw 2 completely
down into the jack body.

Store the hydraulic vehicle jack and the lifting
handle in a dry environment and protected from
moisture.

Ensure that the support plate 1 is fully lowered
and the extension screw 2 is completely screwed
in before you put away the vehicle jack. This will
prevent the oil escaping from the oil plug
8 .

Grease all moving parts on the vehicle jack
regularly to prevent corrosion.
 Troubleshooting
= Fault
= Cause
= Remedy
= The vehicle jack does not raise the vehicle at
all or does not raise it high enough.
= The release valve 5 was not properly closed.
= Close the release valve 5 completely (see the
section on “Raising the vehicle“).
= There is not enough hydraulic oil in the vehicle
jack.
= Top up the hydraulic oil (see the section on
“Topping up the hydraulic oil / greasing“).
= There is too much hydraulic oil in the cylinder.
= Remove the excess quantity of hydraulic oil from
the cylinder.
= There is air in the hydraulic system.
= Remove the air in the hydraulic system (see the
section on “Removing air from the hydraulic
system“).
= The vehicle jack gives way under load.
= The release valve 5 was not properly closed.
= Close the release valve 5 completely (see the
section on “Raising the vehicle“).
= Hydraulic oil escapes.
= There is too much hydraulic oil in the cylinder.
= Remove the excess quantity of hydraulic oil from
the cylinder.
= The pump mechanism works only partially.
= There is too much hydraulic oil in the cylinder.
= Remove the excess quantity of hydraulic oil
from the cylinder.
= There is air in the hydraulic system.
= Remove the air in the hydraulic system (see the
section on “Removing air from the hydraulic
system“).
 Disposal
The packaging and ancillary packing
consist entirely of environmentally-friendly
materials. They can be disposed of at
your local recycling facility.
In the interest of the environment, do not
throw out the product with your house-
hold refuse. Take it to a suitable centre
where it can be disposed of properly.
Your local council will be able to tell you
where the collection centres are located
and their opening times.
Dispose of the hydraulic oil in an environmentally
compatible manner. Ask your local repair garage
to see to its disposal or find your nearest waste
materials collection centre.
 Informations
 Declaration of Conformity
We, Milomex Ltd., c / o Milomex Services, Hilltop
Cottage, Barton Road, Pulloxhill, Bedfordshire,
MK45 5HP, UK, hereby declare under our sole
responsibility that the product: Hydraulic Bottle Jack,
Model No.: Z31224, Version: 07 / 2012, to which
this declaration refers, complies with the standards /
normative documents of 2006 / 42 / EC.
